DOTON DC Motor Solar Pool Pump Kit Swimming Pool Pump Water

  • DOTON DC Motor Solar Pool Pump Kit Swimming Pool Pump Water
  • DOTON DC Motor Solar Pool Pump Kit Swimming Pool Pump Water
  • DOTON DC Motor Solar Pool Pump Kit Swimming Pool Pump Water
  • DOTON DC Motor Solar Pool Pump Kit Swimming Pool Pump Water

DOTON DC Motor Solar Pool Pump Kit Swimming Pool Pump Water

    Min. Order: 1 Piece/Pieces
    Packaging: wooden case
    Supply Ability: 200 Piece/Pieces per Day
    Port: Shanghai/Ningbo

Product Description

DOTON DC Motor Solar Pool Pump Kit Swimming Pool Pump Water

Product Description








Model: TLP27-19-72-1200
Max flow: 27m3/h
Max head: 19m
Voltage: 72V
Power: 1200W
Outlet: 2inch




















Pump Parameters



Model

Power(w)

Voltage (vdc)

Max Flow (m³/h)

Max Head (m)

TLP15-14-48-500

500

48

15

14

TLP20-19-72-900

900

72

20

19

TLP27-19-72-1200

1200

72

27

19

TLP27-19-110-1200

1200

110

27

19

TLP27-19-220/300-1200-A/D

1200

AC220 DC300

19

27

How to Connect


How to connect
Solar panels connect P+ P-.
Pump connect U V W
Very simple connection.


Tips1: Do not reverse the positive and
negative of power, otherwise it will not work.
Tips2: Before you start wiring the controller
box, switch must be in the off position.









Pump Advantages

1. Intlet/ Outlet/ Pump Body/ Impeller:Brass

2. Motor Body: Die-cast Aluminum
3. Bear: NSK/ Screw: 316 stainless steel
4. Motor: Permanent Magnet Brushless DC Motor{Without Hall}
5. Controller: 32bit MCU/ FOC/ Sine Wave Current/ MPPT
6. Controller Shell: Die-cast Aluminum{IP67}
7. Time of warranty: 2 years




MPPT Controller
1.Waterproof grade:IP65
2.MPPT function,the solar power utilization rate is higher.
3.LED displays the power ,voltage, current, speed etc working condition.
4.Automatically start and stop working.
5.Intelligent water shortage protection.
6.Frequency conversion function: It can automatically run with frequency conversion according to the solar power, and user also can change the speed of pump manually.
7.High voltage/Low voltage/Over -
current/High temperature protection.



Application



DOTON DC Motor Solar Pool Pump Kit Swimming Pool Pump Water

Related Products

  3inch dc solar scre  w pump with             3inch dc solar submersible pump                  3inch dc solar pump with

  S/S outlet and inlet                                      with ss impeller                                                   plastic impeller

Customer Reviews



About Us

DOTON

As one of the earliest water pump manufacturers engaged in producing water pump  in china , we believe one day DOTON  pump will exist in every corner of the world by means of its reliable quality and good reputation.

By the way, DOTON sincerely welcomes all the friend to visit our company and hopes to have a good communication and double-win partnership with all of you cause DOTON pump is always on the way to be better! Your views are the driving forces of DOTON! I hereby on behalf of all the members of DOTON , thank all of you for the long-term supporting and concerning of our growth.

FAQ

1. Q:What’s your MOQ?
A:Trial sample order is OK.
2. What’s your payment terms?
A: T/T,L/C.
3. Q: What is the delivery time?
A: 25-30 days after receiving your advanced deposit.
4. Q:Can you we do OEM brand?
A:Yes,welcome your OEM.
5. Q: How to buy our pumps ?
A: Firstly we should know from you :
What is the fluid ?
Clean water(temperature), dirty water(temperature), particles,or slurry ?
What is the flow and head ? And the power?
What is the voltage and frequency of three phase electrcity ?
Other conditions from customer if possible : pump type , motor ?
With complete information, then we selected the pump and feedback to you.
